	Part Number	Description
	111107138	Edge Card Adapter, Universal, for .062 PCB
	111107148	Edge Card Adapter, Universal, for .093 PCB

	Part Number	Description
	410104322	ITA, G12, Front Mount, 12 Module with Protective Cover

	Part Number	Description
	310104408	Receiver, G12, 12 Module, with 15" Platform, for Tabletop
	310104409	Receiver, G12, 12 Module, with 20" Platform, for Tabletop
	310104410	Receiver, G12x, 18 Module, with 15" Platform for Tabletop
	310104411	Receiver, G12x, 18 Module, with 20" Platform for Tabletop

Add To Quote
