QuadraPaddle Signal

QuadraPaddle contacts are engineered for flexible interconnect options.

  • Rated at 20,000 Cyles
  • Rated at 5 amps continuous (1250 VAC)
  • 2 oz. insertion force
  • Provide 4 reliable points of contact per pin

Plug & Play Versatility

  • Versatile twin female contacts provide four beams per end to ensure signal integrity from instrumentation to the Unit Under Test (UUT)
  • Twin male contacts interconnect to ribbon cable, headers, and other standard connectors
  • Makes system configuration a simple “plug & play” operation and delivers high density, high performance interconnectivity at a lower cost per point

User Manual


Contact - ITA

  • Signal, Contact, ITA, QuadraPaddle, 5 Amp, 22-24 AWG
    Signal, Contact, ITA, QuadraPaddle, 5 Amp, 26-30 AWG
    Signal, Contact, ITA, QuadraPaddle, 5 Amp, .025" Round Post
    Signal, Contact, ITA, QuadraPaddle, 5 Amp, .025" Square Post for Wire Wrap with Anti-Rotation
    Signal, Contact, ITA, QuadraPaddle, Male PCB Pin

Contact - Receiver

  • Signal, Contact, Receiver, QuadraPaddle, 5 Amp, 22-28 AWG, Crimp
    Signal, Contact, Receiver, QuadraPaddle, 5 Amp, Male Adapter, .025" Round Post (Adapter Pin)
    Signal, Contact, Receiver, QuadraPaddle, 5 Amp, Male Adapter, .025" Square Post for Wire Wrap
    Signal, Contact, Receiver, QuadraPaddle, 5 Amp, Twin Female
    Signal, Contact, Receiver, QuadraPaddle, 5 Amp, 22-28 AWG, Crimp

Tool- Crimp

  • Tool, Crimp, QuadraPaddle and TriPaddle,  Receiver and ITA, Locator Required
    Tool, Crimp, QuadraPaddle, Receiver

Tool- Extraction

  • Tool, Extraction, QuadraPaddle, ITA
    Tool, Extraction, QuadraPaddle, Receiver

Tool- Insertion

  • Tool, Insertion, QuadraPaddle, ITA, Wire Wrap Contact

Tool- Locator

  • Tool, Locator, QuadraPaddle, ITA
