Specifications
Weight	.69 lbs [.31 Kg] without protective cover
Frame Material	Nickel-Plated Zinc
Hardware Material	Stainless Steel
Latches	Nickel-Plated Beryllium Copper
Backshell	Nickel-Plated Aluminum
Available Contact Slots	22 Positions
Module Slots	2 Positions
Cycle Life	10,000 Cycles
Operating Temperature	-40?C to 125?C

	Part Number	Description
	610151101	High Speed Insert, Receiver/ITA, SIM, VTAC (Only Available in Patchcords)
	610151102	Blank Insert Kit, Receiver/ITA, SIM, VTAC, 10 Pieces

	Part Number	Description
	310113461	Keying Pin Kit, iSeries, Receiver and ITA

	Part Number	Description
	410112924	Protective Cover, i2 Micro iCon, ITA

	Part Number	Description
	310130113	Receiver, i2 MX, 22 Position, EMI-Shielded

	Part Number	Description
	910112130	Tool, Extraction, VTAC, Receiver and ITA

Add To Quote
