Specifications
Pressure/Vacuum Rated	100psi [6.9 Bar]
Contact Body	Nickel Plated Brass
Cycle Life	20,000

	Part Number	Description
	510108111	Mini Coax, Module, ITA, 90 Series, 19 Position
	510108115	Mini Power, Module, ITA, 90 Series, 19 Position
	510108132	Mini Coax, Module, ITA, 90 Series, 76 Position
	510108178	Signal/Mini Power, Module, ITA, TriPaddle, 90 Series, 16/16 Position
	510108210	Signal / Mini Coax, Module, ITA, TriPaddle, 90 Series, 16/16 Position

	Part Number	Description
	510161102	Signal / Mini Power/ Mini Coax, Module, ITA, QuadraPaddle, iCon Series, 100/8 Position
	510161103	Signal / Mini Power/ Mini Coax, Module, ITA, TriPaddle, iCon Series, 64/8 Position
	510161104	Mini Power / Mini Coax, Module, ITA, iCon Series, 24 Position
