Versatile PCB Contacts

VPC contacts are available in a variety of configurations to support flexible PCB mounting including right angle, vertical, twin female & male, and adapter pins (rounded posts).

  • Many PCB receiver contacts are compatible with standard ITA contacts

For questions regarding compatibility, contact a Field Application Engineer.

VPC Solderless Inserts

Pair pass-thru and right-angle solderless inserts for infinite PCB connections for VTAC 12.5+ Gbps high-speed digital, QuadraPaddle signal, and Micropower transmissions.

  • VTAC vertical insert applications can be paired with other SIM inserts loaded with compatible contacts such as 610140109 (Micro Coax, two-piece contacts, PCB vertical mount) to preserve and protect PCB connections


Recommended PCB Configurations

VPC Contacts               LOADED MODULES               VPC MODULES



Accessory

  • 310113562
    Bracket, i2 Micro iCon, Receiver, for PCB Mounting
    510109204
    Header, i2 Micro iCon, Receiver, 84 Pin, for PCB Mounting
    510109206
    Header, i2 Micro iCon, Receiver, 60 Pin, for PCB Mounting
    510109592
    PCB Bracket Kit, SIM Module, Receiver/ITA, for PCB Mounting (Right Angle)

Contact - ITA

  • 610110000
    Signal, Contact, ITA, TriPaddle, Round Post, PCB Mount
    610138115
    Signal, Contact, ITA, QuadraPaddle, 5 Amp, .025" Round Post
    610138123
    Signal, Contact, ITA, QuadraPaddle, Male PCB Pin
    610141109
    Micro Coax, Two Piece Contact, ITA, PCB Vertical Mount, Solder
    610143104
    Micro Power, Contact, ITA, Double Male

Contact - Receiver

  • 610104160
    Mini Coax, Contact, Receiver, Right Angle for PCB Mounting
    610110179
    Signal, Contact, Receiver, TriPaddle, 5 Amp, .025" Round Post
    610138117
    Signal, Contact, Receiver, QuadraPaddle, 5 Amp, Male Adapter, .025" Round Post (Adapter Pin)
    610138200
    Signal, Contact, Receiver, QuadraPaddle, 5 Amp, Twin Female
    610140109
    Micro Coax, Two Piece Contact, Receiver, PCB Vertical Mount, Solder
    610142102
    Micro Power, Contact, Receiver, 21 Amp, PCB Mount
    610142106
    Micro Power, Contact, Receiver
    610142108
    Micro Power, Contact, Receiver, PCB Mount

Insert - Micro Power/Micro Coax

  • 510180104
    Micro Power or Micro Coax, Insert, Receiver, SIM, 2 Pos, 2 Slot (not loaded)
    510181104
    Micro Power or Micro Coax, Insert, ITA, SIM, 2 Pos, 2 Slot (not loaded)

Insert - QuadraPaddle

  • 510180105
    Signal, Insert, Receiver, QuadraPaddle, SIM, Pass-Thru, 4 Pos, 1 Slot
    510181105
    Signal, Insert, ITA, QuadraPaddle, SIM, Pass-Thru, 4 Pos, 1 Slot

Insert - Right Angle

  • 510181103
    Micro Power, Header Insert, Receiver/ITA, SIM, Right Angle, 2 Pos, 2 Slot
    610138126
    Signal, Insert, Receiver/ITA, QuadraPaddle ,SIM, Right Angle, 4 Pos, 1 Slot
    610151104
    VTAC, Insert, Receiver/ITA, SIM, Right Angle, 8 Pos, 1 Slot

Insert - Vertical

  • 610151107
    VTAC, Insert, Receiver/ITA, SIM, Vertical Header, 8 Pos

Insert - VTAC

  • 610151102
    VTAC, Insert, Receiver/ITA, SIM, Blank Insert Kit, 10 Pieces
    610151103
    VTAC, Insert, Receiver/ITA, SIM, Pass-Thru, 8 Pos, 1 Slot

Insert Bundles

  • 510180107
    Signal, Insert Bundle, Receiver, QuadraPaddle, SIM, Right Angle and Pass-Thru
    510181107
    Signal, Insert Bundle, ITA, QuadraPaddle, SIM, Right Angle and Pass-Thru
    610151106
    VTAC, Insert Bundle, Receiver/ITA, SIM, Right Angle and Pass-Thru
    610151108
    VTAC, Insert Bundle, Receiver/ITA, SIM,  Vertical Header and Pass-Thru

Strain Relief Plate

  • 310113582
    Strain Relief Stand-off Kit, iCon, Receiver
    510109598
    Strain Relief Plate, Receiver/ITA, SIM, PCB or wired solutions
